Product Feature
- The snow blade can choose independent hydraulic power drive, working voltage 24V.
- The snow blade has automatic obstacle avoidance, automatic reset function, when removing snow cutting force, speed, snow distance;
- Push the snow blade hydraulic control left and right steering, steering angle of ± 30 °, easy to quickly change the direction of snow clearing. It is convenient to remove the thin snow on the pavement and boardwalk.
- Steel structure reinforced design, the bottom wear-resistant material of the blade plate can be replaced. The blade plate is bolted to the snow pusher plate, making replacement and maintenance quick and easy.
- The steel pin locking device is adopted, so that the snow blade can push hard snow as well as remove floating snow, which improves the utilisation rate of the product.
- Please install the limiting block by yourself according to the host (collecting bucket, tipping bucket).
Specifications
| Model | BM18100 | BM18120 | BM18140 | BM18160 |
|---|---|---|---|---|
| Total width (inch) | 98.43 | 118.11 | 141.73 | 161.42 |
| Overall length (inch) (without pendant) | 67.24 | 67.24 | 67.24 | 67.24 |
| Total height (inch) | 48.43 | 48.43 | 48.43 | 48.43 |
| Shovel body horizontal working swing angle (°) | ±30 | ±30 | ±30 | ±30 |
| Flat angle tilt 30° width (inch) | 85.24 | 102.36 | 122.44 | 139.76 |
| Maximum height of obstacle avoidance (inch) | 8.27 | 8.27 | 8.27 | 8.27 |
| Weight (including pendant) (lbs) | 2755.77 | 3086.47 | 3384.09 | 3747.85 |
| Hydraulic independent unit | Options | Options | Optional | Options |
| Maximum permissible pressure (Mpa) | 20 | 20 | 20 | 20 |
| Mounting model | 2T Loader | 3T Loader | 3T, 5T Loader |
5T, 7T Loader |
Warranty
We’re here to support you every step of the way. In addition to a 1-year manufacturer’s warranty, our dedicated customer service team is ready to assist with any questions, troubleshooting, or guidance you may need throughout your ownership experience.More warranty Information
