Product Feature
- Engineered for rapid snow clearing, making it ideal for use on highways, airports, and urban roads requiring quick and efficient snow management.
- Equipped with advanced mechanics to throw snow as far as 30 meters. The streamlined snow cone and adjustable snow hat allow precise control over snow direction and placement.
- Designed for quick installation and removal, the snow blower is compatible with loaders of over 50 horsepower, ensuring flexibility and ease of use.
- Powered by a Cummins water-cooled, turbocharged engine with direct injection, the snow blower delivers reliable performance.
- Simplified controls enable one-key operation for engaging the engine clutch, snowball rotation, and adjusting the snow cap swing, ensuring fast and efficient performance.
- Built with high-quality materials, this snow blower is designed to withstand harsh winter conditions and continuous heavy-duty use, ensuring long-lasting reliability.
Specifications
| MODEL | BM15P100I | BM15P120I |
|---|---|---|
| Overall length (excluding pendant) (in) | 84.25 | 84.25 |
| Overall width (in) | 105.59 | 119.29 |
| Overall height (in) | 137.01-154.33 | 144.88-161.42 |
| All up (lbs) | 9260.11 | 10582.19 |
| Snow removal height (in) | 55.12 | 55.12 |
| Number of stranded ches(s) | 2 | 2 |
| Strong Diameter (in) | 18.5 | 18.5 |
| Impeller diameter (in) | 39.37 | 39.37 |
| Working ability (tons/hr) | 2500 | 3000 |
| The imum snow throwing distance (yd) | 32.81 | 49.21 |
| Top lift (in) | 17.72 | 17.72 |
| Horizontal rotation angle (°) | 300 | 300 |
| Side throw angle (°) | - | 120 |
| Voltage (V) | DC24 | |
| Engine power (KW) | 194@2200rpm | 242@2100rpm |
| Applicable area altitude (m) | ≤14763.78 | |
| Adapt to the host | 5T and above loader | 5T and above loader |
Performance Introduction
The BeyondTech wheel loader snow blower is a heavy-duty, high-output snow clearing attachment that converts any loader into a rapid-response winter machine. Driven by a clean-burn Cummins engine snow blower pack, the two-stage, rotary snow blower head chews through deep drifts and blasts powder through an adjustable chute and streamlined snow cone for precise, long-distance placement—keeping lanes, runways, and logistics hubs open even in blizzard conditions.
Fast, Controlled Snow Management
- High-speed snow blower rotor and impeller clear wide paths at road speed, perfect for emergency work on toll roads, container yards, and industrial parks.
- Hydraulic chute rotation & snow-cap swing let operators aim left, right, or top-discharge on the fly, preventing wind-row build-up along guardrails.
- Adjustable snow cone / precision snow placement system minimizes follow-up cleanup, whether you’re blowing across a median or over airport blast fences.
Built for Extreme Duty
- Steel-plate housing, corrosion-resistant paint, and heavy gearbox internals create a rugged snow blower ready for harsh-winter salt and grit.
- Low-vibration, balanced design and an operator-friendly control panel reduce fatigue during marathon shifts.
- Quick-attach coupler and clutch-engage PTO get you from bucket to fast-install snow blower in minutes.
Engineered for continuous-duty, low-maintenance service, the BeyondTech wheel loader high-capacity snow blower is the solution municipal fleets, contractors, and property-management teams trust when every minute counts and every lane must stay open.
Performance Video
Warranty
We’re here to support you every step of the way. In addition to a 1-year manufacturer’s warranty, our dedicated customer service team is ready to assist with any questions, troubleshooting, or guidance you may need throughout your ownership experience.More warranty Information
