Product Feature
- Ensures high-efficiency sweeping with a powerful, direct connection to the roller brush, delivering consistent and clean performance.
- Utilizes a polyethylene steel wire mixed brush wire for superior wear resistance and longevity, with a stepless adjustment mechanism that maintains optimal contact for the cleanest sweep.
- Features a one-key unloading system for fast and straightforward operation. The bucket bottom includes a removable wear-resistant plate to extend its service life.
- The motor installation is designed for rapid brush replacement, significantly boosting operational efficiency and reducing maintenance downtime.
Specifications
| Model | BM13110NP |
|---|---|
| Overall length (in) | 77.76 |
| Overall width (in) | 135.43 |
| Overall height (in) | 58.07 |
| Total weight (including pendant) (lbs) | 4673.79 |
| Sweeping width (in) | 110.24 |
| Brush roller diameter (in) | 31.5 |
| Collector hopper capacity (ft³) | 102.36 |
| Air volume (ft³/min) | 88286.7 |
| Filtration precision (μm) | <10 |
| Working flow rate (gal/min) | 42.27-52.83 |
| Working pressure (psi) | 232-348 |
Performance Introduction
- The BeyondTech wheel loader negative-pressure dust sweeper is a dual-motor, direct-drive brush sweeper that couples to any universal loader hitch in minutes and turns your machine into a mobile vacuum broom for factories, quarries, and highway projects.
- Two high-torque hydraulic motors spin a wide roller brush dust sweeper inside a sealed hood; simultaneous suction pulls fines into the hopper, transforming dusty clean-ups into true dust-less sweeping with minimal airborne particulate.
- At the heart of the design is a steplessly adjustable polyethylene/steel-wire brush whose height can be dialed in from the cab for perfect, low-wear contact on concrete, asphalt, or paver blocks.
- The mixed bristle formula raises wear life by 1.5 × over standard wafers, making this a legitimately long-life brush sweeper for round-the-clock industrial duty.
- When the hopper is full, twin cylinders lift the body for a one-key hydraulic tipping-bucket unload—no manual vibration, no clouds of dust—so you’re back sweeping in seconds. A bolt-on, wear-resistant bottom plate protects the bucket floor and swaps out quickly when it finally shows its age.
- Solid, anti-shock front casters and 360° rear plane-bearing wheels give the heavy-duty dust sweeper a smooth ride across uneven ground—ideal for construction dust sweeping, mining haul-roads, or airport aprons—while the low-noise, energy-saving airflow keeps operator fatigue in check. A quick-replace motor mount lets you swap drive units without pulling the whole head, cutting downtime for fleets and municipal yards that can’t afford idle iron.
- Whether you need a wheel loader vacuum dust sweeper for port terminals, a road-maintenance dust control sweeper for highway crews, or a factory floor dust extraction sweeper to meet air-quality mandates, the BeyondTech negative-pressure system delivers rugged performance, easy upkeep, and a cleaner jobsite every single shift.
Performance Video
Warranty
We’re here to support you every step of the way. In addition to a 1-year manufacturer’s warranty, our dedicated customer service team is ready to assist with any questions, troubleshooting, or guidance you may need throughout your ownership experience.More warranty Information
