Product Feature
- Made from high-strength steel plates for superior reliability and durability.
- Removable wear-resistant steel plate at the bucket bottom reduces wear and extends service life.
- Mixed wire brush featuring high-elasticity plastic wires and durable 32SiMnTi steel wires minimizes road damage and lowers operating costs.
- Ensures smooth operation with a quick-insertion installation mode for easy brush replacement.
- Anti-hydraulic impact system safeguards the motor during start and stop operations.
- Equipped with warning sight width marking bars on both sides for improved operational safety.
- Can be fitted with a high-pressure atomization dust removal system and a side brush sweeping device to expand functionality.
- Users should install the appropriate limiting block (tipping bucket, collecting bucket) according to the host machine's setup.
Specifications
| Model | BM13100 | BM13110 |
|---|---|---|
| Overall length (in) | 76.77 | 90.35 |
| Overall width (in) | 118.54 | 136.42 |
| Overall height (in) | 37.4 | 44.88 |
| Gross weight (including pendant) (lbs) | 3230.34 | 4566.84 |
| Hopper capacity (ft³) | 92.09 | 102.36 |
| Effective sweeping width (in) | 100 | 110.24 |
| Brush roller diameter (in) | 31.5 | 31.5 |
| Allowable maximum pressure (psi) | 3046 | 3046 |
| Working flow rate (gal/min) | 47.55-52.83 | 52.83-63.40 |
| Working speed (mph) | 3.11-4.05 | 3.11-4.05 |
