Product Feature
- One-key automatic dumping from the cabin
- No vibrational unloading required
- Simplifies operation and prolongs service life
- Four Solid-Tire Universal Wheels (400-8)
- Ensures smooth maneuverability and stability, even when turning
- Anti-shock and anti-vibration front wheels enhance safety on uneven surfaces
- Rear wheels feature internal plane bearings for reliable 360° rotation under heavy loads
- Increases operational safety and efficiency
- Reduces operator fatigue by avoiding backward operation
- Minimizes the physical risks associated with traditional sweeping methods
- Automatically adapts to uneven terrain for improved cleaning performance
- Easy to replace due to bolt and hinged shaft design
- Maintains consistent contact with the ground, ensuring a thorough sweep
Specifications
| Model | BM12100Ⅱ | BM12110Ⅱ |
|---|---|---|
| Overall length (in) | 104.17 | 110.79 |
| Overall width (in) | 132.68 | 137.4 |
| Overall height (in) | 48.62 | 48.62 |
| Gross weight (lbs) | 4563 | 4973 |
| Hopper capacity (ft³) | 56.5 | 72.45 |
| Effective sweeping width (in) | 101.57 | 110.24 |
| Brush roller diameter (in) | 31.5 | 31.5 |
| Allowable maximum pressure (psi) | 3045.75 | 3045.75 |
| Working flow rate (GPM) | 47.55-52.83 | 52.83-63.40 |
| Working speed (mph) | 3.11-4.04 | 3.11-4.04 |
Warranty
We’re here to support you every step of the way. In addition to a 1-year manufacturer’s warranty, our dedicated customer service team is ready to assist with any questions, troubleshooting, or guidance you may need throughout your ownership experience.More warranty Information
