Product Feature
- The bucket is designed to provide excellent visibility of the cutting edge, enabling greater precision during loading, leveling, and material handling tasks.
- Built with reinforced high-strength materials, the bucket delivers high breakout forces and is reinforced in critical areas, such as the back of the bucket, for added durability and long-lasting performance.
- Equipped with a ¾-inch x 6-inch high-carbon cutting edge, the bucket provides superior durability and extended service life. This edge ensures smooth operation even under heavy-duty use.
- The cast mounting frame enhances the bucket’s structural integrity, improving its durability and extending its service life, even in demanding environments.
- The bucket’s round back design facilitates easier loading and cleaning, ensuring maximum efficiency during operation. This feature minimizes material buildup and improves overall performance.
- Reinforces the cutting edge and strengthens the bottom of the bucket for enhanced durability, providing long-term reliability with minimal additional weight.
- The top and bottom sections of the bucket are formed with a channel design, offering additional strength and durability to handle heavy workloads.
Specifications
| Model | 010360 | 010366 | 010372 | 010384 |
|---|---|---|---|---|
| Inside Bucket Width (in) | 60.2 | 66.1 | 72 | 83.9 |
| Blade Width (in) | 62.2 | 68.1 | 74 | 85.8 |
| Overall Length (in) | 33.1 | 33.1 | 33.1 | 33.1 |
| Overall Height (in) | 21.3 | 21.3 | 21.3 | 21.3 |
| Flat Loading Capacity (cu. ft.) | 12 | 13.4 | 14.1 | 16.2 |
| Weight (Including Hitch) (lbs) | 452 | 469.5 | 480.6 | 496 |
| Optional accessories | Optional secondary blade or tooth | |||
| Suit to machine | Skid steer loader | |||
Warranty
We’re here to support you every step of the way. In addition to a 1-year manufacturer’s warranty, our dedicated customer service team is ready to assist with any questions, troubleshooting, or guidance you may need throughout your ownership experience.More warranty Information
